ASRock DeskMini 310 Series [7/63] Specifications
![ASRock DeskMini 310 Series [7/63] Specifications](/views2/1692950/page7/bg7.png)
2 3
English
1.2 Specications
System
Model
•
DeskMini 310
•
DeskMini 310/COM
•
DeskMini 360
•
DeskMini 370
Chassis
•
1.92L (155 x 155 x 80mm)
CPU
•
Supports 9
th
and 8
th
Gen Intel® Core
TM
Processors (Socket
1151, up to TDP 65W)
CPU cooling
•
Supports Standard Intel Box Fan Coolers
Mother-
board
•
H310M-STX (Mini-STX) (for DeskMini 310)
•
H310M-STX/COM (Mini-STX) (for DeskMini 310/COM)
•
B360M-STX (Mini-STX) (for DeskMini 360)
•
Q370M-STX (Mini-STX) (for DeskMini 370)
Chipset
•
Intel® H310 Chipset (for DeskMini 310, 310/COM series)
•
Intel® B360 Chipset (for DeskMini 360 series)
•
Intel® Q370 Chipset (for DeskMini 370 series)
Graphics
•
Intel® UHD Graphics
Memory
•
Supports DDR4 2666MHz, 2 x SO-DIMM Slots, Max. 32GB
Audio
•
Realtek ALC233 Audio Codec
LAN
•
Intel Gigabit I219V LAN (for DeskMini 310, 310/COM & 360
series)
•
Intel Gigabit I219LM LAN (for DeskMini 370)*
*Supports Intel® vPro
TM
Tech nolog y
Expansion
Slots
•
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
and Intel® CNVi (Integrated WiFi/BT)
•
1 x SD Card Socket (Supports SDXC Card (3.3V))
