14
2.4 Expansion Slots
There are 2 M.2 sockets and 1 PCI Express slot on this motherboard.
M.2 sockets:
1 x M.2 (Key E, 2230) with PCIe x1, USB 2.0 and CNVio for Wireless.
1 x M.2 (Key M, 2242/2260/2280) with PCIE x4 and SATA3 for SSD.
PCIE slot:
PCIE1 (PCIE 3.0 x16 slot) is used for PCI Express x16 lane width cards,
support riser card x8/x8, x8/x4/x4.
M.2 Socket Pin Denition:
M.2 Key-E Socket (M2E1) M.2 Key-M Socket (M2M1)
