ASRock IMB-1225 [6/40] Specifications
![ASRock IMB-1225 [6/40] Specifications](/views2/1693205/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in x 1.5-in)
Processor
System
CPU
Intel
®
10
th
Gen (Cometlake-S) Core™
Processors, up to 65W
*The performance of CPUs over 65W will be
limited due to power design.
Chipset Intel
®
H410
Socket LGA1200
BIOS AMI SPI 128 Mbit
Expansion
Slot
M.2
1 x M.2 (Key E, 2230) with PCIe x1, USB 2.0 for
Wireless
PCIe 1 x PCIe x16 (Gen3)
Memory
Technology
Dual Channel DDR4 2933/2666/2400 MHz
- Intel
®
Core i9/i7 CPUs support DDR4 up to
2933 MHz
- Intel
®
Core i5/i3 CPUs support DDR4 up to
2666 MHz
- Intel
®
Pentium/Celeron CPU support DDR4 up
to 2400 MHz
Capacity 64GB (32 GB per DIMM)
Socket 2 x 260-pin SO-DIMM
Graphics
Controller Intel
®
UHD Graphics
DisplayPort
DisplayPort 1.4, DP++
Max resolution up to 4096x2160@60Hz
HDMI
HDMI 1.4
Max resolution up to 4096x2160 @30Hz
VGA Max resolution up to 1920x1200@60Hz
LVDS Dual channel 24 bit up to 1920x1200@60Hz
MultiDisplay Quad Display
Audio
Interface
Realtek ALC897 HD, High Denition Audio.
Line-out, Mic-in.
Ethernet
Controller/
Speed
LAN1: Intel
®
I219V with 10/100/1000 Mbps
LAN2: Intel
®
I210 with 10/100/1000 Mbps
Connector 2 x RJ-45
