![ASRock IMB-A160 [20/50] Audio amp output speaker header](/views2/1693519/page20/bg14.png)
20
1. High Denition Audio supports Jack Sensing, but the panel wire on
the chassis must support HDA to function correctly. Please follow
the instructions in our manual and chassis manual to install your
system.
2. If you use an AC’97 audio panel, please install it to the front panel
audio header by the steps below:
A. Connect Mic_IN (MIC) to MIC2_L.
B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to
OUT2_L.
C. Connect Ground (GND) to Ground (GND).
D. MIC_RET and OUT_RET are for HD audio panel only. You don’t
need to connect them for AC’97 audio panel.
E. To activate the front mic.
For Windows
®
XP / XP 64-bit OS:
Select “Mixer”. Select “Recorder”. Then click “FrontMic”.
For Windows
®
8 / 8 64-bit / 7 / 7 64-bit / Vista
TM
/ Vista
TM
64-bit OS:
Go to the “FrontMic” Tab in the Realtek Control panel. Adjust
“Recording Volume”.
Audio AMP Output
Speaker Header
(4-pin SPEAKER_OUT1)
(see p.10, No. 34)
1
OU TL N
OU TL P
OU TR P
OU TR N
PIN Signal Name
1 SPK L+
2 SPK L-
3 SPK R-
4 SPK R+
1
Chassis Fan Connector
(3-pin CHA_FAN1)
(see p.10, No. 38)
Please connect a fan cable
to the fan connector and
match the black wire to the
ground pin.
GND
+ 12V
FA N_SPEED
