ASRock IMB-142 Series [5/16] Specifications
![ASRock IMB-142 Series [5/16] Specifications](/views2/1693623/page5/bg5.png)
5
1.2 Specifications
Form
Factor
Dimensions - Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
- Intel
®
Dual-Core Atom™ CedarView Processor
D2550/N2600/N2800
- Supports Hyper-Threading Technology
Core
Number
- 2
Max Speed
- D2550/N2800: 1.86 GHz
- N2600: 1.6GHz
L3 Cache - N/A
Chipset - NM10
BIOS - UEFI
Expansion
Slot
PCI - 1
Mini-PCIe - 1 (Full Size)
mSATA - 0
PCIe - 0
CFast Card
Socket
- 0
Memory
Technology - Single Channel DDR3 800/1066 MHz SDRAM
Max.
- D2550/N2800: 4GB
- N2600: 2GB
Socket
- D2550/N2800: 2 x SO-DIMM
- N2600: 1 x SO-DIMM
Graphics
Controller
- Intel
®
PowerVR SGX545, Support Directx9
compliant Pixel Shader v3.0 and OGL 3.0
VRAM - Shared Memory
VGA
- By Header, supports max resolution
1920x1200
LVDS
- Single Channel 18bits, max resolution
1440x900
HDMI
- Supports HDMI 1.3a, max resolution
1920x1200
DVI - Yes, supports max resolution 1920x1200
Display Port - No
Multi Display - Yes
Ethernet
Ethernet - 10/100/1000 Mbps
Controller - GbE LAN: 2 x Intel
®
WG82574L
Connector - 2 x RJ-45
