10
1.4 Specifications (IMB-161-D)
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA1155 for Intel
®
Core i7/i5/i3/Celeron
(Sandy Bridge and Ivy Bridge)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L3 Cache (By CPU)
Chipset H61
BIOS UEFI
Expansion
Slot
PCI 0
Mini-PCIe 1 (Half Size with USB 2.0)
mSATA 0
PCIe 1 (x16) (IVY Bridge: Gen3; Sandy Bridge: Gen2)
CFast Card
Socket
0
Memory
Technology
Dual Channel DDR3 1066/1333/1600 MHz
SDRAM
Max. 16GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
HD Graphics (By CPU)
VRAM Shared Memory
VGA No
LVDS No
HDMI Supports HDMI 1.4a, max resolution 1920x1200
DVI Support max resolution 1920x1200
Display Port Supports max resolution 2560x1600
Multi Display Yes
Ethernet
Ethernet 10/100/1000 Mbps
Controller GbE LAN1:Intel
®
82583V, LAN2: Intel
®
82579V
Connector RJ-45 x 2 w/ LED
SATA
Max Data
Transfer
Rate
4 x SATA2 (3.0Gb/S)
Rear I/O
VGA 0
DVI 1 (DVI-I)
HDMI 1
DisplayPort 1
Ethernet 2
