12
1.5 Specifications (IMB-161-L)
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA1155 for Intel
®
Core i7/i5/i3/Celeron
(Sandy Bridge and Ivy Bridge)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L3 Cache (By CPU)
Chipset H61
BIOS UEFI
Expansion
Slot
PCI 0
Mini-PCIe 1 (Half Size with USB 2.0)
mSATA 0
PCIe 1 (x16) (IVY Bridge: Gen3; Sandy Bridge: Gen2)
CFast Card
Socket
0
Memory
Technology
Dual Channel DDR3 1066/1333/1600 MHz
SDRAM
Max. 16GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
HD Graphics (By CPU)
VRAM Shared Memory
VGA Supports max resolution 2048 x 1536
LVDS
Dual Channel 24-bit, support max resolution
1920x1200
HDMI Supports HDMI 1.4a, max resolution 1920x1200
DVI No
Display Port No
Multi Display Yes
Ethernet
Ethernet 10/100/1000 Mbps
Controller GbE LAN1:Intel
®
82583V, LAN2: Intel
®
82579V
Connector RJ-45 x 2 w/ LED
SATA
Max Data
Transfer
Rate
4 x SATA2 (3.0Gb/S)
Rear I/O
VGA 1
DVI 0
HDMI 1
