13
DisplayPort 0
Ethernet 2
USB 6 (2 x USB 2.0 compliant)
Audio 2 (Mic-in, Line-out)
Serial 2 (RS-232/422/485)
PS/2 1 (Combo)
Internal
Connector
USB 2 (USB 2.0 compliant)
LVDS/
Inverter
0
VGA 0
Serial 4 (RS-232)
SATA 4 x SATA2 (3.0Gb/s)
mPCIe 1
Parallel 0
mSATA 0
IrDA 0
GPIO 8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
0
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR ATX PWR (24+4 pin)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
