Primary Plane Current Limit

Use this item to congure the maximum instantaneous current allowed for

the primary plane. The default value is [Auto].

Secondary Plane Current Limit

Use this item to congure the maximum instantaneous current allowed for

the secondary plane. The default value is [Auto].

Intel Hyper Threading Technology

To enable this feature, a computer system with an Intel processor that sup-

ports Hyper-Threading technology and an operating system that includes

optimization for this technology, such as Microsoft

Windows

XP / Vista

7 / 8 is required. Set to [Enabled] if using Microsoft

Windows

XP, Vista

7, 8, or Linux kernel version 2.4.18 or higher. This option will be hidden if

the installed CPU does not support Hyper-Threading technology.

Active Processor Cores

Use this item to select the number of cores to enable in each processor

package. The default value is [All].

Enhance Halt State (C1E)

All processors support the Halt State (C1). The C1 state is supported

through the native processor instructions HLT and MWAIT and requires no

hardware support from the chipset. In the C1 power state, the processor

maintains the context of the system caches.

CPU C3 State Support

Use this to enable or disable CPU C3 (ACPI C2) report to OS.

CPU C6 State Support

Use this to enable or disable CPU C6 (ACPI C3) report to OS.

Package C State Support

Selected option will program into C State package limit register. The

default value is [Auto].

CPU Thermal Throttling

You may select [Enabled] to enable CPU internal thermal control

mechanism to keep the CPU from overheating.

No-Execute Memory Protection

No-Execution (NX) Memory Protection Technology is an enhancement

to the IA-32 Intel Architecture. An IA-32 processor with “No Execute (NX)

Memory Protection” can prevent data pages from being used by malicious

software to execute codes. This option will be hidden if the current CPU

does not support No-Excute Memory Protection.
