20
Buzzer Header
(2-pin BUZZ1)
(see p.8 No. 27)
1
+5 V
SP KR
Chassis Intrusion Headers This motherboard supports
(2-pin CI1, CI2)
CASE OPEN detection feature
(see p.8 No. 24)
that detects if the chassis cover
has been removed. This feature
requires a chassis with chassis
intrusion detection design.
TPM Header This connector supports
(17-pin TPM1)
Trusted Platform Module (TPM)
(see p.8 No. 20)
system, which can securely
store keys, digital certicates,
passwords, and data. A TPM
system also helps enhance
network security, protects
digital identities, and ensures
platform integrity.
1
GN D
GN D
S_ PWRDWN#
LA D2
SM B_CLK_M AIN
PC ICLK
PC IRST#
LA D3
+3 V
LA D0
GN D
FR AME
SM B_DATA_ MAIN
LA D1
SE RIRQ#
GN D
+3 VSB
48 MHz
+5 V
Inverter Power Control Wafer
(6-pin BLT_PWR1)
(see p.8 No. 6)
PIN Signal Name
1 GND
2 GND
3 CON_LBKLT_CTL
4 CON_LBKLT_EN
5 LCD_BLT_VCC
6 LCD_BLT_VCC
1
1
Signal
GND
