ASRock SBC-211P [6/37] Specifications
![ASRock SBC-211P [6/37] Specifications](/views2/1693645/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions 3.5" SBC (5.8-in x 4.0-in) / (148 x 102 mm)
Processor
System
CPU
Intel
®
new Atom™ Baytrail-E3800 Series
Supports Hyper-Threading Technology
Default E3826 Dual core processor
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
Cache (By CPU)
Chipset N/A
BIOS UEFI
Expansion
Slot
PCI 0
Mini-PCIe 1 (Half Size) + 1 (Full Size) shared with mSATA
mSATA 1 (Full Size) shared with SATAII_2
PCIe 0
CFast Card
Socket
0
Memory
Technology Single Channel DDR3L 1066/1333 MHz SDRAM
Max. 8GB
Socket 1 x SO-DIMM
Graphics
Controller Intel
®
Gen7 Intel Graphics DX 11, OGL3.2
VRAM Shared Memory
VGA Supports max. resolution 1920 x 1200
LVDS
Dual channel 24-bit, max resolution 1920 x 1200
@60Hz
HDMI
Supports HDMI 1.4a, max resolution 1920 x
1200
DVI N/A
DisplayPort N/A
Multi Display Yes (Dual Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller GbE LAN: Realtek RTL8111G-CG
Connector 2 x RJ-45
SATA
Max Data
Transfer
Rate
SATA2 (3.0Gb/s)
Rear I/O
VGA 1
DVI 0
HDMI 1
DisplayPort 0
