7
Ethernet 2
USB 2 x USB 3.0 compliant
Audio 1 ( Line out)
Serial 0
PS/2 0
Internal
Connector
USB 6 ( 3*2.54 pitch header USB 2.0 compliant)
LVDS/
Inverter
1/1
VGA 0
Serial 4 (RS-232)
SATA
2x SATA2 (3.0Gb/s) (SATAII_2 is shared
with mSATA)
Parallel 0
IrDA 0
GPIO 8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output From Super I/O to drag RESETCON#
Interval 256 segments, 0,1,2…255sec/min
Power
Requirements
Input PWR 9-36V DC-In using 4-pin ATX PWR Con
Power On
AT/ATX Supported
AT: Directly PWR on as power input ready
ATX: Press button to PWR on after power
input ready
Environment
Temperature 0ºC – 60ºC
