4 5
English
Rear Panel
I/O
•
1 x DC Jack (Compatible with the 19V power adapter)*
* Please use 90W power adapter for 65W CPU and 65W power
adapter for 35W CPU.
•
1 x Headphone Jack
•
1 x D-Sub Port
•
1 x HDMI Port
•
1 x DisplayPort 1.2
•
4 x USB 2.0 Ports (Support ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
Storage
•
1 x SATA3 6.0 Gb/s with Power Connector , support NCQ,
AHCI and Hot Plug
•
1 x Ultra M.2 Socket, support type 2280 M.2 SATA3 6.0 Gb/s
module and M.2 PCI Express module up to Gen3 x4
(32 Gb/s)*
* Supports NVMe SSD as boot disks
Connector
•
1 x COM Port Header
•
1 x Chassis Intrusion Header
•
1 x CPU Fan Connector (4-pin)
•
1 x Internal Speaker Header
•
1 x Front Panel Header
•
1 x Mono-Out Header
•
1 x ROM Recovery Header
BIOS
Feature
•
AMI UEFI Legal BIOS with multilingual GUI support
•
ACPI 5.0 Compliant wake up events
•
SMBIOS 2.7 Support
Hardware
Monitor
•
CPU Temperature Sensing
•
CPU Fan Tachometer
•
CPU Quiet Fan (Auto adjust chassis fan speed by CPU
temperature)
•
CPU Fan Multi-Speed Control
•
CASE OPEN detection
•
Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
OS
•
Microso® Windows® 10 64-bit
