ASRock ROMED8QM-2T [10/88] English
![ASRock ROMED8QM-2T [10/88] English](/views2/1694143/page10/bga.png)
4 5
English
System BIOS
BIOS Type 32MB AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU / RTL8211E/X550 Environment Temperature Sensing
- MB_A/MB_B/Card Side Temperature Sensing
Fan - CPU/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
+BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows®
- Server 2016 (64 bit)
- Server 2019 (64 bit)
Linux®
-RedHat Enterprise Linux Server 8.0 (64 bit)/ 7.6 (64 bit)
- CentOs 8.0 ( 64 bit) / 7.6 ( 64 bit)
- SUSE SLES 15.1 (64 bit) / 12.4 (64 bit)
- UBuntu 18.04.3 (64 bit) / 16.04.6 (64 bit)
- CITRIX Hypervisor 8.1
Virtual:
- VMWare ESXi 6.5 u3 / 6.7 u3
- vSphere 6.5 u3/ 6.7 u3
* e SUSE Enterprise Linux Server 15.1 (64 bit) / 12.4 (64 bit) system only
supports UEFI BOOT.
* Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
NOTE: Please refer to our website for the latest specications.
is motherboard supports Wake from on Board LAN. To use this function, please
make sure that the “Wake on Magic Packet from power o state” is enabled in Device
Manager > Intel® Ethernet Connection > Power Management. And the “PCI Devices
Power On” is enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration.
Aer that, onboard LAN1&2 can wake up S5 under OS.
