ASRock ROMED8QM-2T [8/88] Specifications
![ASRock ROMED8QM-2T [8/88] Specifications](/views2/1694143/page8/bg8.png)
2 3
English
1.2 Specications
ROMED8QM-2T
MB Physical Status
Form Factor ATX
Dimension 12'' x 9.6'' (30.5 cm x 24.4 cm)
Processor System
CPU AMD EPYC™ 7002/7001 Series Processor Family (ROME)
Socket Single Socket SP3 (LGA4094)
Chipset N/A
System Memory
Type - Eight Channel DDR4 memory technology
- Supports DDR4 RDIMM, LRDIMM
DIMM Size Per
DIMM
- RDIMM: 64GB*,32GB, 16GB, 8GB
- LRDIMM: 128GB**, 64GB*, 32GB
- NV DIMM:32GB***
*64GB: wait for the device to be validated
**128GB: wait for the device to be validated
***Wait for the device to be validated
DIMM Frequency - RDIMM: 3200MHz
- LRDIMM: 2666MHz
- NVDIMM: 2666MHz*
*Wait for the device to be validated
Voltage 1.2V
Expansion Slot
PCIe 4.0 x 16 PCIE1: Gen4 x16 link
PCIE6: Gen4 x16 link
Storage
SATA Controller 4 x SATA3 6.0 Gb/s (from mini SAS HD , Gen3)
M.2 Slot 1 (2230/2242/2260/2280, SATA x1 or PCIE Gen3 x4)
Slimline SLIM1: PCIe Gen4 x8 (Support SATA )
SLIM2: PCIe Gen4 x8 (Support SATA )
SLIM3: PCIe Gen4 x8
SLIM4: PCIe Gen4 x8
SLIM5: PCIe Gen4 x8
SLIM6: PCIe Gen4 x8 (Support SATA )
SLIM7: PCIe Gen4 x8
Mezzanine - 1 x OCP Mezzanine Type A (Gen3 x8 )
- 1 x OCP Mezzanine Type B (Gen3 x8 )
Ethernet
Interface 10000/1000 /100 Mbps by Intel X550-AT2
