e illustration shows how jumpers are setup. When the jumper cap is placed on
the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is
“Open”.
Manufacturing Mode
Jumper
(2-pin MFG1)
(see p.6, No. 35)
Short two pins to boot Manufactory mode.
2-pin Jumper
NVDIMM Power Mode
Jumpers
(3-pin NV_12V_ 3)
(see p.6, No. 9)
No Power (Default)
+12V for NVDIMM_ABCD
NVDIMM Power Mode
Jumpers
(3-pin NV_12V_4)
(see p.6, No. 2)
No Power (Default)
+12V for NVDIMM_EFGH
