ROMED8QM-2T
2 3
English
LAN Controller - 2 x RJ45 10G base-T by Intel® X550-AT2
- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E
- Supports Wake-On-LAN
- Supports Energy E_cient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2500
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features Watch Dog
NMI
Graphics
Controller ASPEED AST2500
VRAM DDR4 256MB
Rear Panel I/O
VGA Port 1 x D-Sub
Serial port 1 x COM port
USB 3.1 Gen1 Port 2
LAN Port - 2+1 RJ45 Gigabit Ethernet LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID 1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, and front
LAN LED)
Front Panel Header 1
Panel Header 1
TPM Header 1
IPMB Header 1
Fan Header 7 Fans x 6-pin (1CPU/6 Front)
ATX Power 1 x (24-pin) + 1 x (8-pin)
USB 3.1 Gen1
Header
1 (supports 2 USB 3.1 Gen1 ports)
M.2 1(M2_1: 2230/2242/2260/2280, SATA x1 or PCIE Gen3 x4
SATA SGPIO 4
CPU HSBP 1
BMC SMB 1
PSU SMB 1
TR 1
NMI Button 1
80 debug port LED 1
Speaker(4pin) 1
ClearCMOS 1
OH/FanFail LED 7 (only Fan Fail LED)
