SiBE81-909 Specifications
Humidifying Air Purifier 11
4.4 Packaging Drawing
Power supply code
Body
Product cover
Wireless remote controller ASSY
A
Deodrizing cartridge pack
Pleats filter
Accesory bag ASSY
VIEW A
C : 2P241869A
