SiBE81-909 Precautions for Use
Humidifying Air Purifier 5
2. Precautions for Use
2.1 Required Conditions
Power Supply
1φ, 220-240/220-230V, 50/60Hz
Miscellaneous
•
This product is for home use. Do not use for special purpose.
•
This product is for indoor use only. Do not use in bathroom or outdoors as it is not water/condensation proof.
•
Do not modify this product.
2.2 Applicable Room Area
Note) The applicable room area is appropriate for the operating unit of maximum fan speed (HH).
Applicable room area indicates the space where a certain amount of dust particles can be removed in 30 minutes.
(JEM1467)
Air purifying operation Humidifying operation
m
2
46
—
