ASRock X399D8A-2T [10/84] English
![ASRock X399D8A-2T [10/84] English](/views2/1694218/page10/bga.png)
4 5
English
Type A USB 3.1
Gen1 Port
1
USB 3.1 Gen1
Header
1 ( support 2 USB3.1 Gen1)
USB 2.0 Header 1 ( support 2 USB2.0)
ClearCMOS 1 (short pad)
NMI button 1
Front Panel 1
Buzzer 1
80 debug port
LED
1
PWR_SMB 1
OH/FanFail LED 6 (Fan Fail LED only )
System BIOS
BIOS Ty pe 128Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
- Card side Temperature Sensing
- System TR Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: Vcore, VCCMAB, VCCMCD, 3v, 5v,
12v, 1.05V_PCH, +BAT, 3VSB, 5VSB, 5V_Dual, VcoreNB
GPU Support
Technolog y Supports AMD Quad-GPU CrossFireX™ Technology
Support OS
OS Microso® Windows®
- Windows 10 (64 bit)
Linux®
- RedHat Enterprise Linux Server 7.3 (64bit) / 7.6 (64bit)
- CentOs 7.3 (64 bit) / 7.6 (64 bit)
- UBuntu 16.04 (64 bit) / 18.04 (64 bit)
Virtual:
- VMWare ESXi 6.5 u1
* AMD RAID mode does not support Linux OS installation.
* Please refer to our website for the latest OS support list.
