ASRock X399D8A-2T [14/84] English
![ASRock X399D8A-2T [14/84] English](/views2/1694218/page14/bge.png)
8 9
English
No. Description
1 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2, White)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1, Blue)
3 ATX 12V Power Connector (ATX12V2)
4 ATX 12V Power Connector (ATX12V1)
5 ATX Power Connector (ATXPWR1)
6 PSU SMBus (PSU_SMB1)
7 AMD Socket TR4 4094P
8 CPU Fan Connector (FAN1)
9 System Fan Connector (FAN2)
10 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)
11 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)
12 USB 3.1 Gen1 Header (USB3_6_7)
13 M.2 Socket (M2_1) (Type 2230/2242/2260/2280/22110)
14 SATA3 Connector (SATA3_9)
15 SATA3 Connector (SATA3_8)
16 SATA3 Connector (SATA3_5)
17 SATA3 Connector (SATA3_4)
18 System Fan Connector (FAN4)
19 MINI-SAS HD Connector (SATA3_0_3)
20 USB 2.0 Header (USB_1_2)
21 System Fan Connector (FAN6)
22 Vertical Type A USB 3.1 Gen1 (USB3_5)
23 System Panel Header (PANEL1)
24 Auxiliary Panel Header (AUX_PANEL1)
25 System Fan Connector (FAN5)
26 System Fan Connector (FAN3)
27 SATA3 DOM Connector (SATA3_6), Red
28 SATA3 DOM Connector (SATA3_7), Red
29 ermal Sensor Header (TR1)
30 SATA DOM Power Jumper (SATAPWR1)
31 SATA DOM Power Jumper (SATAPWR2)
32 Clear CMOS Pad (CLRMOS1)
33 TPM Header (TPMS1)
