ASRock TRX40D8-2N2T [10/86] English
![ASRock TRX40D8-2N2T [10/86] English](/views2/1694219/page10/bga.png)
4 5
English
80 Debug Port
LED
1
Front LAN LED 1
OH/FanFail LED 6 (Fan Fail LED only )
System BIOS
BIOS Type 32Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
- Card side Temperature Sensing
- System TR Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +3VSB, +5VSB, VCORE, VCORE_NB,
VCCM_AB, VCCM_CD, BAT, 3V, 5V, 12V
GPU Support
Tech nology Supports AMD Quad-GPU CrossFireX™ Technology
Support OS
OS Microso® Windows®
- Windows 10 (64 bit)
Linux®
- CentOS 8.1 (64 bit)
*e Linux system does not support Raid mode.
* Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
NOTE: Please refer to our website for the latest specications.
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
