ASRock TRX40D8-2N2T [14/86] English
![ASRock TRX40D8-2N2T [14/86] English](/views2/1694219/page14/bge.png)
8 9
English
No. Description
1 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2, White)*
2 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1, Blue)*
3 ATX 12V Power Connector (ATX12V2)
4 ATX 12V Power Connector (ATX12V1)
5 ATX Power Connector (ATXPWR1)
6 PSU SMBus (PSU_SMB1)
7 AMD Socket TR4 4094P
8 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)*
9 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)*
10 USB 3.2 Gen1 Header (USB3_6_7)
11 System Fan Connector (FAN1)
12 System Fan Connector (FAN2)
13
SATA3 Connector (A_SATA1) (Upper), SATA3 Connector (A_SATA0)
(Lower)
14 System Fan Connector (FAN3)
15 SATA3 Connector (SATA1) (Upper), SATA3 Connector (SATA0) (Lower)
16 System Fan Connector (FAN5)
17 System Fan Connector (FAN6)
18 Vertical Type A USB 3.2 Gen1 (USB3_5)
19 SATA DOM Power Connector (SATAPWR2)
20 SATA3 DOM Connector (SATA3), Red
21 System Panel Header (PANEL1)
22 Auxiliary Panel Header (AUX_PANEL1)
23 System Fan Connector (FAN4)
24 COM Port Header (COM1)
25 SATA3 DOM Connector (SATA2), Red
26 USB 2.0 Header (USB_1_2)
27 M.2 Socket (M2_1) (Type 2230/2242/2260/2280/22110)
28 SATA DOM Power Connector (SATAPWR1)
29 Clear CMOS Pad (CLRMOS1)
30 TPM Header (TPM1)
31 Speaker Header (SPEAKER1)
32 ermal Sensor Header (TR1)
