1.2 Specications
TRX40D8-2N2T
MB Physical Status
Form Factor ATX
Dimension 12'' x 9.6'' (30.5 cm x 24.4 cm)
Processor System
CPU Supports AMD Ryzen™ readripper™ TR4+ Series Processors
Socket AMD Socket TR4 4094P
Chipset AMD TRX40
System Memory
Capacity - 8 x 288-pin DDR4 DIMM slots
- Supports up to 256GB DDR4 ECC & non-ECC U-DIMM
Type - Dual Channel Memory Technology
- Supports DDR4 ECC U-DIMM
Voltage 1.2V
DIMM Size per
DIMM
ECC U-DIMM: 32GB, 16GB, 8GB, 4GB
DIMM Frequency ECC / non-ECC U-DIMM: 4666(OC)+ / 4600(OC) /
4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) /
4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) /
3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 /
2133 MHz
Expansion Slot
PCIe 4.0 x 16 SLOT3: Gen4 x16 link
SLOT5: Gen4 x16 link
SLOT7: Gen4 x16 link
PCIe 4.0 x 8
(open-ended)
SLOT1: Gen4 x 8 link
M.2 2 x M-key (PCIe4.0 x4) support 2230/2242/2260/2280/22110
Storage
SATA Controller TRX40: 2 x SATA 6Gb/s; 2x SATA DOM, support RAID 0, 1,
10
Additional SATA
Controller
Asmedia 1061: 2 x SATA3 6.0 Gb/s (A_SATA0/A_SATA1)
Ethernet
Interface 10Gbps/2.5Gbps
LAN Controller - 2 x RJ45 10GbEby Intel® X710-AT2
- 2 x RJ45 2.5GbEby Intel® i225
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports PXE
- LAN3 Supports NCSI
