![ASRock TRX40D8-2N2T [42/86] English](/img/pdf.png)
ASRock TRX40D8-2N2T [42/86] English
![ASRock TRX40D8-2N2T [42/86] English](/views2/1694219/page42/bg2a.png)
36 37
English
NUT1NUT2DE
Step 6
Tighten the screw with a screwdriver
to secure the module into place.
Please do not overtighten the screw as
this might damage the module.
