![ASRock D1622D4I [10/74] English](/views2/1694236/page10/bga.png)
4 5
English
Hardware Monitor
Temperature
- CPU/PCH/DDR/LAN/Storage Temperature Sensing
- MB/Card side Temperature Sensing
Fan
- Fan Tachometer
- Fan Multi-Speed Control
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
Volt age
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
Support OS
OS Linux®
- Red Hat Enterprise Linux Server 7.7 (64 bit) / 8.1 (64 bit)
- CentOs 7.7 (64 bit) / 8.1 (64 bit)
- SUSE Enterprise Linux Server 12 SP4 (64 bit) / 15 SP1 (64 it)
- Fedora 30 (64 bit)
- FreeBSD 11.3 (64 bit)
- Ubuntu 19.10 (64 bit)
* Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
* For detailed product information, please visit our website: http://www.asrockrack.com
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility, this motherboard may fail Windows® Hardware Quality
Lab (WHQL) certication tests. If you install the drivers only, it will pass the WHQL tests.
