D1622D4I / D1600D4I-2L2T
PB 1
English
Chapter 1 Introduction
ank you for purchasing ASRock Rack D1622D4I / D1600D4I-2L2T motherboard,
a reliable motherboard produced under ASRock Rack’s consistently stringent quality
control. It delivers excellent performance with robust design conforming to ASRock
Rack’s commitment to quality and endurance.
1.1 Package Contents
•
ASRock Rack D1622D4I / D1600D4I-2L2T Motherboard
(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.02 cm x 17.02 cm)
•
1 x Mini SAS Cable (6G) (60cm)
•
1 x I/O Shield
•
1 x Screw for M.2 Socket
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/
