EPC621D4I-2M / EPC621D6I
16 17
English
1. Before you installed the heatsink, you need to spray thermal interface material between the CPU
and the heatsink to improve heat dissipation.
2. Illustration in this documentation are examples only. Heatsink or fan cooler type may dier.
3
4
180
o
