ASRock EPC621D4I-2M [8/81] Specifications
![ASRock EPC621D4I-2M [8/81] Specifications](/views2/1694413/page8/bg8.png)
2 3
English
1.2 Specications
EPC621D4I-2M / EPC621D6I
MB Physical Status
Form Factor Mini ITX
Dimension 6.7'' x 6.7'' (17.02 cm x 17.02 cm)
Processor System
CPU Intel® Xeon® Scalable Processors
Socket Single Socket LGA3647 (Socket P)
Chipset Intel® C621
System Memory
Capacity EPC621D4I-2M:
- 4 x 260-pin DDR4 DIMM slots
- Support up to 64GB DDR4 SO-RDIMM and *SO-ECCDIMM
EPC621D6I:
- 6 x 260-pin DDR4 DIMM slots (4*DIMM on top, 2*DIMM
on bottom)
- Support up to 96GB DDR4 SO-RDIMM and *SO-ECCDIMM
*Conditionally supported. For details, please refer to Memory QVL on the
ocial website.
Type EPC621D4I-2M:
- Four Channel DDR4 memory technology
- Support DDR4 2933*/2666/2400/2133 SO-RDIMM and
**SO-ECCDIMM
EPC621D6I:
- Six Channel DDR4 memory technology
- Support DDR4 2933*/2666/2400/2133 SO-RDIMM and *SO-
ECCDIMM
*DDR4 2933 memory is supported only when using the Intel Cascade Lake
CPU and Intel Cascade Lake BIOS.
**Conditionally supported. For details, please refer to Memory QVL on the
ocial website.
DIMM Size Per
DIMM
EPC621D4I-2M:
SO-RDIMM, SO-ECC DIMM: 32GB, 16GB, 8GB, 4GB
EPC621D6I:
SO-RDIMM, SO-ECC DIMM: 32GB, 16GB, 8GB, 4GB
DIMM
Frequency
SO-RDIMM, SO-ECC DIMM: 2933*/2666/2400/2133 MHz
*DDR4 2933 memory is supported only when using the Intel Cascade Lake
CPU and Intel Cascade Lake BIOS.
Voltage 1.2V
Expansion Slot
PCIe 3.0 x 16 PCIE3: Gen3 x16 link (from CPU1)
