EPC621D4I-2M / EPC621D6I
2 3
English
Storage
SATA
Controller
EPC621D4I-2M:
Intel® C621: 7 x SATA3 6Gb/s (4 from mini-SAS HD , 1 x SATA
DOM 6Gb/s and 2 x M.2 on bottom)), support RAID 0, 1, 5, 10
EPC621D6I:
Intel® C621: 5 x SATA3 6Gb/s (4 from mini-SAS HD and 1 x
SATA DOM 6Gb/s), support RAID 0, 1, 5, 10
M.2 2 X2280, (PCIE(x4)/SATA3)
Ethernet
Interface 1000 /100 /10 Mbps
LAN 2 x 1GbE RJ45 via Intel integrated MAC X722 + Marvell®
Alaska® 88E1514
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2500
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2500
VRAM DDR4 256MB
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.1 (Gen1)
Port
2
LAN Port 2 x RJ45 Gigabit Ethernet LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
Internal Connector
TPM Header 1
Fan Header 3Fans x 4-pin (CPU/2System)
ATX Power 1 (24-pin) + 1 (8-pin)
USB 2.0 Header 1 ( support 2 USB 2.0)
BMC SMB
Header
1
PSU SMBus
Header
1
Front Panel
Header
1
Clear CMOS 1 (short pad)
NVME Support 1 x MINISASHD from PCH
COM Header 1 (from BMC)
