ASRock EP2C612D16FM2 [41/99] Pin con29
![ASRock EP2C612D16FM2 [41/99] Pin con29](/views2/1694586/page41/bg29.png)
EP2C612D16FM2
34 35
English
Pin Defeinition Pin Defeinition
1 PWM_FRONT2_SWB 2 GND
3 PWM_FRONT1_SWB 4 CLK_100M_PLX_CLK1_R_DP
5 TACH_SWB_FAN1 6 CLK_100M_PLX_CLK1_R_DN
7 TACH_SWB_FAN3 8 GND
9 TACH_SWB_FAN5 10 CLK_100M_DB1900_CLK_R_DP
11 TACH_SWB_FAN6 12 CLK_100M_DB1900_CLK_R_DN
13 TACH_SWB_FAN8 14 GND
15 PWM_CPU1_SWB 16 CLK_100M_PLX_CLK3_R_DP
17 SWB_PRESENT_N 18 CLK_100M_PLX_CLK3_R_DN
19 GND 20 GND
21 CLK_100M_PLX_CLK2_R_DP 22 CLK_100M_PLX_CLK4_R_DP
23 CLK_100M_PLX_CLK2_R_DN 24 CLK_100M_PLX_CLK4_R_DN
25 GND 26 GND
27 CPU1_PE2D_TX_C_DP15 28 CPU1_PE2D_RX_DP15
29 CPU1_PE2D_TX_C_DN15 30 CPU1_PE2D_RX_DN15
31 GND 32 GND
33 CPU1_PE2D_TX_C_DP14 34 CPU1_PE2D_RX_DP14
35 CPU1_PE2D_TX_C_DN14 36 CPU1_PE2D_RX_DN14
37 GND 38 GND
39 CPU1_PE2D_TX_C_DP13 40 CPU1_PE2D_RX_DP13
41 CPU1_PE2D_TX_C_DN13 42 CPU1_PE2D_RX_DN13
43 GND 44 GND
45 CPU1_PE2D_TX_C_DP12 46 CPU1_PE2D_RX_DP12
47 CPU1_PE2D_TX_C_DN12 48 CPU1_PE2D_RX_DN12
49 GND 50 GND
51 CPU1_PE2C_TX_C_DP11 52 CPU1_PE2C_R X_DP11
53 CPU1_PE2C_TX_C_DN11 54 CPU1_PE2C_RX_DN11
55 GND 56 GND
57 CPU1_PE2C_TX_C_DP10 58 CPU1_PE2C_RX_DP10
59 CPU1_PE2C_TX_C_DN10 60 CPU1_PE2C_RX_DN10
61 GND 62 GND
63 CPU1_PE2C_TX_C_DP9 64 CPU1_PE2C_RX_DP9
65 CPU1_PE2C_TX_C_DN9 66 CPU1_PE2C_RX_DN9
67 GND 68 GND
69 CPU1_PE2C_TX_C_DP8 70 CPU1_PE2C_RX_DP8
71 CPU1_PE2C_TX_C_DN8 72 CPU1_PE2C_RX_DN8
73 GND 74 GND
75 CPU1_PE2B_TX_C_DP7 76 CPU1_PE2B_RX_DP7
77 CPU1_PE2B_TX_C_DN7 78 CPU1_PE2B_RX_DN7
79 GND 80 GND
81 CPU1_PE2B_TX_C_DP6 82 CPU1_PE2B_RX_DP6
120-pin Con29
