![ASRock FH-C612NM [14/95] English](/img/pdf.png)
ASRock FH-C612NM [14/95] English
![ASRock FH-C612NM [14/95] English](/views2/1694706/page14/bge.png)
8 9
English
No. Description
1 SATA SGPIO Connector 1 (SATA_SGPIO1)
2 PSU SMBus (PSU_SMB1)
3 USB 2.0 Header (USB_1_2)
4 ATX Power Connector (ATXPWR1)
5 Vertical Type A USB 3.0 (USB3_5)
6 USB 3.0 Header (USB3_3_4)
7 Mini-SAS Connector (SATA_2_5)
8 Mini-SAS Connector (SSATA_0_3)
9 SATA3 Connector (SATA_0)
10 SATA3 Connector (SATA_M0)
11 SATA3 Connector (SATA_1)
12 SATA3 Connector (SATA_M1)
13 CPU PECI Mode Jumper (PECI1)
14 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)
15 Front Fan Connector (FRNT_FAN5)
16 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)
17 Front Fan Connector (FRNT_FAN4)
18 ATX 12V Power Connector (ATX12V1)
19 LGA 2011 CPU Socket R3 (Narrow ILM) (CPU1)
20 CPU1 Fan Connector (CPU1_FAN1)
21 Front Fan Connector (FRNT_FAN3)
22 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2, White)
23 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1, Blue)
24 2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_F1, Blue)
25 2 x 288-pin DDR4 DIMM Slots (DDR4_E2, DDR4_F2, White)
26 Front Fan Connector (FRNT_FAN2)
27 Front Fan Connector (FRNT_FAN1)
28 Front Fan Connector (FRNT_FAN6)
29 CPU2 Fan Connector (CPU2_FAN1)
30 LGA 2011 CPU Socket R3 (Narrow ILM) (CPU2)
31 ATX 12V Power Connector (ATX12V2)
32 2 x 288-pin DDR4 DIMM Slots (DDR4_H2, DDR4_G2, White)
33 2 x 288-pin DDR4 DIMM Slots (DDR4_H1, DDR4_G1, Blue)
