ASRock FH-C612NM [17/95] English
![ASRock FH-C612NM [17/95] English](/views2/1694706/page17/bg11.png)
FH-C612NM
10 11
English
No. Item Status Description
1 FAN_LED5 Amber FRNT_FAN5 failed
2 FAN_LED4 Amber FRNT_FAN4 failed
3 FAN_LED7 Amber CPU1_FAN1 failed
4 FAN_LED3 Amber FRNT_FAN3 failed
5 FAN_LED2 Amber FRNT_FAN2 failed
6 FAN_LED1 Amber FRNT_FAN1 failed
7 FAN_LED6 Amber FRNT_FAN6 failed
8 FAN_LED8 Amber CPU2_FAN1 failed
9 SB_PWR1 Green STB PWR ready
10 BIOS_B_LED Amber BU1_B is in operation
11 BIOS_A_LED Amber BU1_A is in operation
12 BMC_LED1 Green BMC heartbeat LED
