1.2 Specications
FH-C612NM
MB Physical Status
Form Factor SSI EEB
Dimension 12'' x 13'' (30.5 cm x 33.0 cm)
Processor System
CPU Intel® Xeon processor E5-2600/4600 v3/v4 series
Socket Dual Socket LGA 2011 R3
Chipset Intel® C612
System Memory
Capacity 16 DIMM slots
Type - Quad Channel memory technology
- Supports 2400*/2133/1866 LR/R/ECC NVDIMM
*Only E5-2600 V4 CPUs support DDR4 2400.
Voltage 1.2V
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
Expansion Slot
PCIe 3.0 x 16 2 slots
NGFF 1, M key PCIe x4(CPU1) and SATA NGFF SATA3(shared with
PCH SATA1)
Mezzanine 1 PCIex8(CPU1) with NCSI
Mezzanine 2 PCIex8(CPU2)
Mini PCIe M.2, Mini PCIe from PCH
Storage
SATA
Controller
Intel C612: 10x SATA3, 2 pcs 4 port SFF-8087 CONN (8 ports),
2x SATA 7p (SATA1 shared with M.2), support RAID 0, 1, 5, 10
Ethernet
Interface N/A
LAN N/A
Management
BMC Controller ASPEED AST2400
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features Watch Dog
Graphics
Controller ASPEED AST2400
VRAM DDR3 2Gb
