WC422D8A-2T / WC422D8A-2T/U
4 5
English
Virtual
- VMWare® Workstation 12
- Citrix XenServer 7.5
- Win hyper-V Server 2016
* Please refer to our website for the latest OS support list.
* On Ubuntu 16.04 (64bit) system, Intel Raid mode only supports UEFI BOOT.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
GPU Support
Technolog y - Supports NVIDIA® 4-Way SLI™ Technology
- Supports AMD Quad-GPU CrossFireX™ Technology
NOTE: Please refer to our website for the latest specications.
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN or Marvell SATA utility, this motherboard may fail Windows®
Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it will
pass the WHQL tests.
