![ASRock WC422D8A-2T/U [9/99] English](/views2/1694710/page9/bg9.png)
WC422D8A-2T / WC422D8A-2T/U
2 3
English
LAN - 2 x RJ45 GLAN by Intel® X550
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 Supports NCSI
Management
BMC Controller ASPEED AST2500 : IPMI (Intelligent Platform Management
Interface) 2.0 with Ikvm and vMedia support
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features NMI
Graphics
Controller ASPEED AST2500
VRAM DDR4 4GB
Audio
Audio Codec Realtek ALC892
Rear Panel I/O
PS/2 KB/mouse 1
VGA Port 1 x D-Sub
USB 3.0 Port 4
USB 3.1 Port 2 (1 type A, 1 type C)
LAN Port - 2 x RJ45 Gigabit Ethernet LAN ports
- 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
Audio 1(5+1 jack)
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, and front
LAN LED)
VGA Header 1
COM Header 1
SATA DOM 1
TR1 1
TPM Header 1
IPMB Header 1
PMBus Header 1
BMC SMBus
Header
1
Fan Header 6 x 6-pin Fans (1CPU/5 system)
ATX power 1x (24-pin) + 1x (8-pin)
Type A USB 3.0
Port
1
USB 3.0 Header 1 ( supports 2 USB3.0 ports)
USB 2.0 Header 1 ( supports 2 USB2.0 ports)
