ASRock WC422D8A-2T/U [14/99] English
![ASRock WC422D8A-2T/U [14/99] English](/views2/1694710/page14/bge.png)
8 9
English
No. Description
1 Non Maskable Interrupt Button (NMI_BTN1)
2 ATX Power Connector (ATXPWR1)
3 PSU SMBus Header (PSU_SMB1)
4 Chassis ID0 Jumper (CHASSIS_ID0)
5 BMC SMBus Header (BMC_SMB_1)
6 Chassis ID1 Jumper (CHASSIS_ID1)
7 Chassis ID2 Jumper (CHASSIS_ID2)
8 Intelligent Platform Management Bus Header (IPMB_1)
9 CPU PECI Mode Jumper (PECI1)
10 Enable/Disable BMC Jumper (MFG_N)
11 Front Fan Connector (FRNT_FAN1)
12 Front Fan Connector (FRNT_FAN2)
13 Front Fan Connector (FRNT_FAN3)
14 Front Fan Connector (FRNT_FAN4)
15 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)*
16 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)*
17 ATX 12V Power Connector (ATX12V1)
18 PWM Conguration Header (PWM_CFG1)
19 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2, White)*
20 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1, Blue)*
21 Front Fan Connector (FRNT_FAN5)
22 SATA3 Connector (SATA_6)
23 SATA SGPIO Connector (SATA_SGPIO1)
24 SATA SGPIO Connector (SATA_SGPIO2)
25 SATA3 Connector (SATA_5)
26 SATA3 Connector (SATA_4)
27 SATA3 Connector (SATA_3)
28 SATA3 Connector (SATA_2)
29 SATA3 Connector (SATA_1)
30 SATA3 Connector (SATA_0)
31 SATA3 Connector (M_SATA_1)**
32 SATA3 Connector (M_SATA_0)**
33 Vertical Type A USB 3.0 (USB3_7)**
