No. Description
34 M.2 Socket (M2_1) (Type 2230/2242/2260/2280/22110)***
35 Virtual RAID On CPU Header (VROC1)
36 TPM Header (TPMS1)
37 USB 2.0 Header (USB2_1_2)
38 SATADOM Power Jumper (SATAPWR1)
39 USB 3.0 Header (USB3_5_6)
40 SATA3 DOM Connector (SATA_7)
41 System Panel Header (PANEL1)
42 Auxiliary Panel Header (AUX_PANEL1)
43 Power LED and Speaker Header (SPK_PLED1)
44 Clear CMOS Jumper (CLRMOS1)
45 ermal Sensor Header (TR1)
46 COM Port Header (COM1)
47 Front Panel Audio Header (HD_AUDIO1)
48 OCULink x4 Connector (OCU1)
49 OCULink x4 Connector (OCU3)
50 OCULink x4 Connector (OCU4)
51 M.2 Socket (M2_2) (Type 2230/2242/2260/2280/22110)***
52 OCULink x4 Connector (OCU2)
53 CPU Fan Connector (CPU1_FAN1)
54 Front VGA Header (FRNT_VGA1)
*For DIMM installation and conguration instructions, please see p.24 (Installation of Memory Modules
(DIMM)) for more details.
**By default, USB3_7 supports a USB 2.0 device and both M_SATA_0 and M_SATA_1 are enabled.
To enable USB3_7 to support a USB 3.0 device, please go to the BIOS Settings: BIOS Menu > Advanced > USB
Conguration > USB3_7 Select. Please note that if USB3_7 supports a USB 3.0 device, M_SATA_0 and M_
SATA_1 are disabled.
*** If M2_1 is occupied by a SATA-type M.2 device, SATA_7 will be disabled.
