WC422D8A-2T / WC422D8A-2T/U
36 37
English
Baseboard Management
Controller SMBus Header
(5-pin BMC_SMB_1)
BMC_SMB_PRESENT_1_N
Power
BMC_SMBCLK
GND
BMC_SMBDATA
is header is used for the SM
BUS devices.
ermal Sensor Header
(3-pin TR1)
1
TR1 TR1
GND
Please connect the thermal
sensor cable to either pin 1-2
or pin 2-3 and the other end to
the device which you wish to
monitor its temperature.
PWM Conguration
Header
(3-pin PWM_CFG1)
1
GND
SMB_DATA_VSB
SMB_CLK_VSB
is header is used for PWM
congurations.
Power LED and Speaker
Header
(7-pin SPK_PLED1)
1
+5V
DUMMY
PLED+
PLED+
PLED-
DUMMY
SPEAKER
Please connect the
chassis power LED and
the chassis speaker to
this header.
