ASRock E3C242D4M-4L [10/87] English
![ASRock E3C242D4M-4L [10/87] English](/views2/1694714/page10/bga.png)
4 5
English
Buzzer 1
SGPIO 2
BMC_SMB1 1
PSU_SMB1 1
Smbus from
BMC
1
PWR_SMB 1
USB 3.0 Type A 1 (by bom option for USB3.0 or USB2.0)
* when USB 2.0 Type Ax1, USB 3.0 header x 2 port
* when USB 3.0 Type Ax1, USB 3.0header x1 port
USB 3.0 Header 1 (support 2 USB 3.0, by bom option for 2 port USB3.0 or 1
port USB3.0)
* when 2 port USB 3.0, 1port USB 2.0 Type A
* when 1 port USB 3.0, 1port USB 3.0 Type A
USB 2.0 Header 2 (support 4 USB 2.0)
M.2 E3C246D4M-4L:
1 (2230/2242/2260/2280, Supports PCIE3.0(X4)/SATA3)
E3C242D4M-4L:
1 (2230/2242/2260/2280, Supports PCIE3.0(X2)/SATA3)
NMI Button 1 (Header)
ME/SPS
recovery
1
ClearCMOS 1 (short pin)
OH/FanFail
LED
6 (only Fan Fail LED)
System BIOS
BIOS Type 256Mb AMI UEFI Legal BIOS
BIOS Features -Plug and Play (PnP)
-ACPI 2.0 Compliance Wake Up Events
-SMBIOS 2.8.0 Support
-ASRock Rack Instant Flash
Hardware Monitor
Temperature -CPU Temperature Sensing
-System Temperature Sensing
-MB / Card Side Temperature Sensing
-TR1 Temperature Sensing
Fan -CPU/Rear/Front Fan Tachometer
-CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
-CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, VCCM,
VCCIO, VCCSA, VCCST_SFR,V1.0M, 3VSB, 5VSB, VBAT
