ASRock E3C242D4M-4L [30/87] Expansion slots pci express slots
![ASRock E3C242D4M-4L [30/87] Expansion slots pci express slots](/views2/1694714/page30/bg1e.png)
24 25
English
2.6 Expansion Slots (PCI Express Slots)
ere are 2 (E3C242D4M-4L) or 5 (E3C246D4M-4L) PCI Express slots on this motherboard.
PCIE slot:
E3C246D4M-4L / E3C242D4M-4L:
PCIE2 (PCIe 3.0 x8 slot) is used for PCI Express x4 lane width cards.
PCIE6 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width cards.
Slot Generation Mechanical Electrical Source
PCIE 6 3.0 x16 x16 CPU
PCIE 2 3.0 x8 x4 PCH
E3C246D4M-4L:
PCIE3, PCIE4 and PCIE5 (PCIe 3.0 x1 slot) are used for PCI Express x1 lane width cards.
Slot Generation Mechanical Electrical Source
PCIE 5 3.0 x1 x1 PCH
PCIE 4 3.0 x1 x1 PCH
PCIE 3 3.0 x1 x1 PCH
PCI Express Slot Conguration
The PCIE6 slot shares lanes with the mezzanine card slot (MEZZ_1). When MEZZ_1 is
populated with a mezzanine card, the PCIE6 slot will operate at up to x8 mode.
PCIE6
No mezzanine card x16
MEZZ_1 is populated x8
Installing an expansion card
Step 1. Before installing an expansion card, please make sure that the power
supply is switched o or the power cord is unplugged. Please read the
documentation of the expansion card and make necessary hardware
settings for the card before you start the installation.
Step 2. Remove the system unit cover (if your motherboard is already installed
in a chassis).
Step 3. Remove the bracket facing the slot that you intend to use. Keep the
screws for later use.
Step 4. Align the card connector with the slot and press rmly until the card is
completely seated on the slot.
Step 5. Fasten the card to the chassis with screws.
Step 6. Replace the system cover.
