Daikin FXL63LVE [39/56] Selection procedure
![Daikin FXYCP80K7V19 [39/56] Selection procedure](/views2/1697052/page39/bg27.png)
• Introduction
6
• Systems • Introduction
38
6 Selection procedure
6-3 Selection procedure System based on cooling load
6-3-4 Selection example based on cooling load
1 Given
• Design condition
Cooling : indoor 20°CWB, outdoor 33°CDB
• Cooling load
• Power supply : 3-phase 380V/50Hz
2 Indoor unit selection
Enter indoor unit capacity table at:
20°CWB indoor temperature
33°CDB outdoor air temperature.
Selection results are as follows:
3 Outdoor unit selection
•Assume that the indoor and outdoor unit combination is as follows.
Outdoor unit : RSXYP26K
Indoor unit : FXYCP25K x 3 , FXYCP40K x 5, FXYSP50K x 2, FXYFP80K x 1, FXYMP100K x 2
•Indoor unit combination total capacity index
25 x 3 + 40 x 5 + 50 x 2 + 80 x 1 + 100 x 2 = 655 (100.77 %)
4
Actual performance data (50Hz)
• Outdoor unit cooling capacity : 75.78kW (RSXYP26K, 100.77 %)
→direct interpolation between 100 and 110 %
•Individual capacity
Capacity of FXYCP25K = 75.78 x
25
= 2.89kW
655
Capacity of FXYCP40K7 = 75.78 x
40
= 4.63kW
655
Capacity of FXYSP50K = 75.78 x
50
= 5.78kW
655
Capacity of FXYFP80K = 75.78 x
80
= 9.25kW
655
Capacity of FXYMP100K = 75.78 x
100
= 11.57kW
655
Actual combination capacity
Room A B C D E F G H
Load (kW) 2.9 2.7 2.5 4.3 4.0 4.0 3.9 4.2
Room A B C D E F G H I J K L M
Load (kW) 2.9 2.7 2.5 4.3 4.0 4.0 3.9 4.2 5.4 5.8 8.7 10.9 10.8
Unit size 25 25 25 40 40 40 40 40 50 50 80 100 100
Capacity 3.0 3.0 3.0 4.8 4.8 4.8 4.8 4.8 5.9 5.9 9.5 11.9 11.9
Room A B C D E F G H I J K L M
Load (kW) 2.9 2.7 2.5 4.3 4.0 4.0 3.9 4.2 5.4 5.8 8.7 10.9 10.8
Unit size 25 25 25 40 40 40 40 40 50 50 80 100 100
Capacity 2.89 2.89 2.89 4.63 4.63 4.63 4.63 4.63 5.78 5.78 9.25 11.57 11.57
