Griven GRAPH-i-LINE 20 [23/28] Dmx address setting

English 23

5.2 DMX address setting

The DMX address can be set only by using the accessory AL2660 Weezerd 1. Refer to the manual of the

accessory.

The order recipt is confirmed by the lighting of the green, red and blue LEDs in sequence.

5.3 Setting DMX mode AL4375

The DMX mode can be set only by using the accessory AL2660 Weezerd 1. Refer to the manual of the accessory.

The order recipt is confirmed by the lighting of all the LEDs in sequence according to the selected DMX mode.

5.4 DMX Functions AL4375

Each unit uses from 3 to 60 DMX channels.

For each pixel see the following table:

Attention!

The DMX address must be set anly on the first unit of the daisy-chain.•

DMX MODE DMX CHANNELS USED BY THE UNIT N° PIXELS

0 60 20

1 30 10

2 15 5

3 12 4

4 6 2

5 3 1

Attention!

In the absence of DMX signal, the LEDs will run a diaagnostic lighting test as soon as the fixture is powered and

then they will stay off.

DMX CHANNELS USED BY THE UNIT N° PIXELS

60 20

30 10

15 5

12 4

6 2

3 1

Function Value Description

Red 0-255 Proportional control 0-100% of the Red color

Green 0-255 Proportional control 0-100% of the Green color

Blue 0-255 Proportional control 0-100% of the Blue color
