AL4700 Graph-i-Dot - Rev. 1.00
page 3 of 12
551073
WARNING ! xing and connecting operations must mandatorily be carried out by qualied personnel only !
ATTENZIONE ! le operazioni di installazione e connessione devono obbligatoriamente essere eseguite solo da per-
sonale specializzato !
WARNING ! Ensure power supply is o before connecting or disconnecting xtures !
ATTENZIONE ! Assicurarsi che l’alimentazione sia disattivata prima di collegare o scollegare i proiettori!
Connecting Graph-i-Dot to the Start line Kit ( AL4703 ).
FROM DMX
CONTROLLER
2
DATA +
DATA -
COMMON
A
B
-GND
+VCC
AD
N.C.
N.C.
N.C.
4
1
L=30mm
L=8mm
L=30mm
L=8mm
3
