Griven GRAPH-i-DOT [5/12] Typical system diagram
![Griven GRAPH-i-DOT [5/12] Typical system diagram](/views2/1700066/page5/bg5.png)
AL4700 Graph-i-Dot - Rev. 1.00
page 5 of 12
551073
Typical system diagram:
Graph-i-Dot chain
110~266 VAC 50/60Hz
110~266 VAC 50/60Hz
DMX CONTROLLER
AL4703 Start Line kit
AL4704
Power joint Kit
AL4705
Joint Kit
AL4706
Terminator cap
AL4704
Power joint Kit
AL4702
Electronic
Driver
AL4702
Electronic
Driver
