36 | APPENDIX I: Specicaons in Other Languages
Spanish
Especicaciones
Compabilidad con el
procesador
Ranura 1151 para procesador Intel® Core i7 / i5 / i3 / Penum / Celeron
Alimentación de Proyección Térmica (TDP – Thermal Design Power): 95Wa
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el procesador.
Tipo de Placa INTEL® B150
Memoria
Soporta DDR4 2133/1866 Doble Canal
4x DDR4 DIMM Ranura de memoria Soporta hasta 64 GB Memoria
Cada DIMM soporta un modulo non-ECC 4/8/16 GB DDR4
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 6x SATA III (6Gb/s)
Ranura 1x PCIe 3.0 x4 M.2 (Key M) (32Gb/s)
Soporta AHCI
LAN
Intel i219V
1x 10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC887
Canales Audio de Alta Denición 7.1, Hi-Fi(Front)
USB
INTEL® B150:
Ranura 6x USB 3.0 (4 en las entrada/salidas posteriores y 2 por los distribuidores internos)
Ranura 6x USB 2.0 (2 en las entrada/salidas posteriores y 4 por los distribuidores internos)
Ranuras de Exnción
Ranura 2x PCIe 3.0 x1
Ranura 1x PCIe 3.0 x16 (x4)
Ranura 1x PCIe 3.0 x16 (x16)
Panel trasero de E/S
Ratón 1x PS/2
Teclado 1x PS/2
Ranura 1x DVI-D
Ranura 1x HDMI
Ranura 4x USB 3.0
Ranura 2x USB 2.0
Ranura 1x LAN
Socket audio 3x
Conectores en placa
Conector 6x SATA III
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Distribuidor 1x USB 3.0 (cada distribuidor soporta 2 ranuras USB 3.0)
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x2
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Factor de Forma Factor de Forma uATX, 230 mm x 244 mm
Soporte OS
Windows 7/ 8.1(64bit)/ 10(64bit)
Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
