4 | 第一章: 主板介绍
1�3 主板特性
规格
CPU支援
Socket 1151，Intel Core i7 / i5 / i3 / Pentium / Celeron处理器
CPU最大热功耗(95Watt)
* 请访问 www.biostar.com.tw 获取CPU的支持列表
芯片组 INTEL® B150
内存
支持双通道DDR4 2133/ 1866
4个DDR4 DIMM插槽，最大内存容量为64GB
每个DIMM支持非ECC 4/ 8/ 16 GB DDR4内存模组
* 请访问 www.biostar.com.tw 获取内存的支持列表
存储器
6个SATA III接口 (6Gb/s)
1个 PCIe 3.0 x4 M.2 (Key M) 插槽 (32Gb/s)
支持AHCI
当使用SATA SSD模块于PCIE-M2插槽时，SATA3_1接口将被禁用。
»
网络
Intel i219V
1x 10/ 100/ 1000 Mb/s自适应传输模式，半双工/全双工工作模式
音效 ALC887 8声道音频输出，支持高清音频，Hi-Fi (前)
USB
INTEL® B150:
6个USB 3.0端口(背板4个端口，板载接头支持2个端口)
6个USB 2.0端口(背板2个端口，板载接头支持4个端口)
扩展槽
2个PCIe 3.0 x1插槽
1个PCIe 3.0 x16插槽 (x4)
1个PCIe 3.0 x16插槽 (x16)
当PEX1_1或PEX1_2插槽被使用时，PEX16_2插槽将在PCIe x2的速度下运行。
»
背板接口
1个PS/2鼠标接口
1个PS/2键盘接口
1个DVI-D端口
1个HDMI端口
4个USB3.0端口
2个USB2.0端口
1个LAN端口
3个音频插孔
板载接口
6个SATA III接口
2个USB2.0接头(每个接头支持2个USB2.0端口)
1个USB3.0接头(每个接头支持2个USB3.0端口)
1个电源接口(8针)
1个电源接口(24针)
1个CPU风扇接头
2个系统风扇接头
1个前置面板接头
1个前置音频接头
1个清空CMOS数据接头1
主板尺寸 uATX Form Factor，230 mm x 244 mm
操作系统支持
Windows 7/ 8.1(64bit)/ 10(64bit)
* 如有增加或减少任何OS支持，Biostar保留不预先通知的权利。
