4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket AM4 supports AMD A-series APU / Ryzen CPU / NPU for Socket AM4
Maximum CPU TDP (Thermal Design Power): 105Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset AMD X470
Memory
Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2667/ 2933(OC)/ 3200(OC)
4 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC and ECC Un-buered 8/ 16 GB DDR4 module
* DDR4 - 2667 only for Ryzen CPU.
* Please refer to www.biostar.com.tw for Memory support list.
Storage
6x SATA III Connector (6Gb/s) : Supports AHCI & RAID 0, 1, 10
1x M.2 (32Gb/s) : Supports PCI-E & SATA SSD
* M.2 (32Gb/s) : The bandwidth is depended on CPU, Ryzen is 32Gb/s / APU, NPU is 16Gb/s.
LAN
Intel i211AT
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC1220
7.1 Channels, High Denion Audio, Hi-Fi(Front + Rear)
USB
1x USB 3.1 Gen2 (10Gb/s) Type-C port (1 on rear I/O)
1x USB 3.1 Gen2 (10Gb/s) Type-A port (1 on rear I/O)
6x USB 3.1 Gen1 (5Gb/s) port (4 on rear I/Os and 2 via internal headers)
2x USB 3.1 Gen1 (5Gb/s) port (2 via internal headers) : supports LIGHTNING CHARGER(not support
USB wake up funcon)
4x USB 2.0 port (4 via internal headers)
Expansion Slots
3x PCIe 2.0 x1 Slot
1x PCIe 2.0 x16 Slot (x4)
2x PCIe 3.0 x16 Slot (When using APU or NPU, the bandwidth is x8 speed)
Rear I/Os
1x PS/2 Keyboard / Mouse
1x DVI-D Port
1x HDMI Port
1x DP Port
1x LAN port
1x USB 3.1 Gen2 (10Gb/s) Type-C Port
1x USB 3.1 Gen2 (10Gb/s) Type-A Port
4x USB 3.1 Gen1 (5Gb/s) Port
5x Audio Jack
1x SPDIF_Out
Internal I/Os
6x SATA III (6.0Gb/s) Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
2x USB 3.1 Gen1 (5Gb/s) Header (each header supports 2 USB 3.1 Gen1 ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
2x CPU Fan Connector
3x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
2x 5050 LED Header
Form Factor ATX Form Factor, 305 mm x 244 mm
OS Support
Windows 7(64bit) / 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.
