Input Voltage
- AC Range
85 - 264 VAC (Full Range)
- DC Range
120 - 370 VDC (Designed for, no certification)
Input Frequency
47 - 63 Hz
Input Current
- Full Load & Vin = 230 VAC
800 mA max.
- Full Load & Vin = 115 VAC
1'700 mA max.
Power Consumption
- at no Load
300 mW max. (Ready to meet ErP directive)
Input Inrush Current
- at 230 VAC
60 A max.
Power Factor
- at 230 VAC
0.95 min. (Active Power Factor Correction)
- at 115 VAC
0.95 min. (Active Power Factor Correction)
Input Protection
T 3.15 A / 250 VAC (Internal Fuse in L & N)
Input Specifications
Output Voltage Adjustment
±10% (By trim potentiometer)
Output power must not exceed rated power!
Voltage Set Accuracy
±1% max.
Regulation
- Input Variation (Vmin - Vmax)
0.2% max.
- Load Variation (0 - 100%)
0.5% max.
Ripple and Noise
(20 MHz Bandwidth)
12 VDC model:
120 mVp-p typ. (with 1 µF X7R)
15 VDC model:
150 mVp-p typ. (with 1 µF X7R)
24 VDC model:
220 mVp-p typ. (with 1 µF X7R)
28 VDC model:
220 mVp-p typ. (with 1 µF X7R)
36 VDC model:
250 mVp-p typ. (with 1 µF X7R)
48 VDC model:
250 mVp-p typ. (with 0.1 µF X7R)
Capacitive Load
12 VDC model:
10'400 µF max.
15 VDC model:
6'600 µF max.
24 VDC model:
2'600 µF max.
28 VDC model:
1'900 µF max.
36 VDC model:
1'150 µF max.
48 VDC model:
650 µF max.
Minimum Load
Not required
Temperature Coefficient
±0.02 %/K max.
Hold-up Time
- at 230 VAC
16 ms min.
- at 115 VAC
16 ms min.
Start-up Time
- at 230 VAC
1'000 ms max.
- at 115 VAC
1'000 ms max.
Short Circuit Protection
Continuous, Automatic recovery
Output Current Limitation
115 - 150% of Iout max.
Overvoltage Protection
115 - 135% of Vout nom.
Transient Response
- Response Deviation
3% max. (50% to 75% Load Step)
- Response Time
500 µs typ. (50% to 75% Load Step)
Output Specifications
Safety Standards
- IT / Multimedia Equipment
UL 60950-1
- Medical Equipment
EN 60601-1
IEC 60601-1
ANSI/AAMI ES 60601-1
2 x MOPP (Means Of Patient Protection)
- Certification Documents
www.tracopower.com/overview/tpp150a-j
Protection Class
Class I Prepared: Connection to PE
Class II Prepared: Reinforced Insulation
Pollution Degree
PD 2
Over Voltage Category
OVC II
Safety Specifications
TPP 150A-J Series, 150 Watt
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
June 4, 2019
Page 2 / 4
