EMC Emissions
EN 60601-1-2 edition 4 (Medical Devices)
- Conducted Emissions
EN 55011 class B (internal filter)
EN 55032 class B (internal filter)
FCC Part 15, class B
FCC Part 18, class B
- Radiated Emissions
EN 55011 class A (internal filter)
EN 55032 class A (internal filter)
FCC Part 15, class A
FCC Part 18, class A
- Harmonic Current Emissions
EN 61000-3-2, class A
EN 61000-3-2, class D
- Voltage Fluctuations & Flicker
EN 61000-3-3
EMC Immunity
EN 55024 (IT Equipment)
EN 60601-1-2 edition 4 (Medical Devices)
- Electrostatic Discharge
Air:
EN 61000-4-2, ±15 kV, perf. criteria A
Contact:
EN 61000-4-2, ±8 kV, perf. criteria A
- RF Electromagnetic Field
EN 61000-4-3, 20 V/m, perf. criteria A
- EFT (Burst)
EN 61000-4-4, ±2 kV, perf. criteria A
- Surge
L to L:
EN 61000-4-5, ±1 kV, perf. criteria A
L to PE:
EN 61000-4-5, ±2 kV, perf. criteria A
- Conducted RF Disturbances
EN 61000-4-6, 20 Vrms, perf. criteria A
- PF Magnetic Field
EN 61000-4-8, 10 A/m, perf. criteria A
- Voltage Dips & Interruptions
230 VAC / 50 Hz:
EN 61000-4-11
30%, 25 periods, perf. criteria A
60%, 5 periods, perf. criteria A
>95%, 0.5 periods, perf. criteria A
>95%, 250 periods, perf. criteria B
EMC Specifications
Relative Humidity
95% max. (non condensing)
Temperature Ranges
- Operating Temperature
–25°C to +85°C
- Storage Temperature
–40°C to +85°C
Power Derating
- High Temperature
see application note
www.tracopower.com/overview/tpp150a-j
- Low Input Voltage
1.33 %/V below 100 VAC
Cooling System
- Option 1
Forced air cooling (with external fan, 10 CFM)
- Option 2
Natural convection (20 LFM)
Fan Power Source
- Characteristic
Variable fan speed (temperature regulated)
- Output Voltage
12 VDC
- Output Current
500 mA max.
Altitude During Operation
5'000 m max.
Switching Frequency
45 - 75 kHz (PWM QR)
Insulation System
Reinforced Insulation
Working Voltage (rated)
250 VAC
Isolation Test Voltage
- Input to Output, 60 s
5'657 VDC
- Input to Case or PE, 60 s
2'828 VDC
- Output to Case or PE, 60 s
2'828 VDC
Isolation Resistance
- Input to Output, 500 VDC
100 MOhm min.
Leakage Current
(264 VAC)
- Touch Current
100 µA max.
Reliability
- Calculated MTBF
786'000 h (MIL-HDBK-217F, ground benign)
Environment
- Vibration
IEC 60068-2-6
- Mechanical Shock
IEC 60068-2-27
Connection Type
JST
Weight
187 g
General Specifications
TPP 150A-J Series, 150 Watt
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
June 4, 2019
Page 3 / 4
